Brand: Nangong, Model: NGADSBM-20/38-4H, Load Capacity: 1.5 tons, Net Weight: 2 tons, Body Size: 4.4 * 2 meters, Color: Black;

Detailed parameters of a 1.5-ton fully automatic hydraulic lifting LED advertising trailer:

1. The dimensions of the vehicle are 4.4 meters in length, 2 meters in width, and 0.79 meters in height;

2. Carrying 1 ton (excluding trailer accessories);

3. The main beam adopts a 120 * 60 * 5mm rectangular tube;

4. Equipped with 4 195/70R15 tires, with a speed of 60km/h;

5. The wheels are equipped with electric brakes and shock absorption functions;

6. The body shape is wrapped with 2mm galvanized iron plate;

7. The traction is a triangular fixed type, without steering function (with a universal wheel support leg attached);

8. Each corner of the vehicle is equipped with a hydraulic support leg, which can be extended and retracted;

9. The screen frame is produced according to the drawings provided by the customer;

10. The screen frame lifting arm is welded with square tubes;

11. The rotation and lifting of the screen frame are both driven by hydraulic transmission;

12. Install three color taillights and seven star sockets at the rear of the vehicle;

13. The hydraulic power unit motor has a DC 12V voltage and requires a 12V120A battery;

14. Equipped with 12V120A maintenance free battery;

15. Raise the screen frame by 1.5 meters;

16. 6 sets of solar installation brackets;

17. Solar support frame;

18. Four sets of solar bracket oil cylinders.

LED advertising trailer customized by Nan Gong is widely used for publicity, product promotion, brand promotion, on-site display, sports events, concerts, and talent shows in enterprises and institutions

Application scenarios: LED advertising trailers are used for on-site display, communication, and interaction with audiences or consumers in busy commercial areas, squares, residential communities, square parks, and other areas. The promotional scope is wide, which can achieve good advertising dissemination effects for customers.
