Manual lifting advertising trailer, mobile trailer chassis

Brand: Nangong, Model: NGTT003-10/12-2H, Table size: 1.2*1m, Load capacity: 0.3 tons, Net weight: 0.4 tons, Color: engineering yellow;

Manual lifting advertising trailer, mobile trailer chassis, detailed parameters (specific details shall be subject to the plan confirmed by both parties)

1. With a load capacity of 0.3 tons, it measures 1.2 meters in length and 1 meter in width (excluding the length of the towing bar);

2. The traction head adopts a towing cover (with a tow ball), and a universal support wheel is installed on one side of the traction rod to facilitate manual movement, which is retracted during driving;

3. The tires are equipped with two 165/70R13 pneumatic tires, with a single wheel load of 0.56 tons and a speed of 60KM/H. The tires are equipped with mudguards;

4. Torsion damping for shock absorption;

5. Lifting: Equipped with a manual lifting rod, with a lifting range of 0.4 meters; Rotation: Manual rotation of 330 degrees;

6. Four manual mechanical legs are installed on the bottom plate of the vehicle body for parking support, which are retracted during driving;

7. Equip both sides of the rear end of the trailer with LED taillights and a dedicated wiring harness;

8. Color: Engineering Yellow;

9. The electric control box, solar panel mounting frame, and display screen mounting frame are the responsibility of the customer.

Manual lifting advertising trailer, mobile trailer chassis, Nango Vehicles specializes in long-term non-standard customization. The trailer chassis features exquisite appearance, low cost, competitive price, and fast delivery, suitable for outdoor locations such as mobile traffic signs and LED advertising screens.
