Brand: Nangong, model: NGTT05-22/50-4S, load capacity: 5 tons, table size: 5 * 2.2 meters, tire model: 600-9. Color: engineering yellow, net weight: 1670KG;

5 ton guardrail type flat trailer full trailer detailed parameters:

1. The Flatbed trolley has a bearing capacity of 5T, with a length of 5m, a width of 2.2m and a height of about 0.75m;

2. The main beam of the platform is made of 8 # steel, the side beam is made of 8 # steel, and the board surface is made of 4mm thick patterned plates;3. This car has 4 solid tires of models 600-9, with a single wheel bearing capacity of 1.9 T and a rated speed of within 15KM/H;

4. The design concept of this car is suspended, and it can adjust the body level and balance the tire load force according to the smoothness of the road surface;

5. The left and right rotation angle of the front wheels is 180 degrees, which is convenient for small radius turning;

6. Height adjustable spring buffered traction mechanism;

7. This vehicle is equipped with spring shock absorbers;

8. This vehicle is equipped with guardrails (height 0.6 meters), and the front end is fixed. The left and right sides and rear end are flip down guardrails;

9. The steering mechanism is a rotary table type machine rotating assembly (5T), which runs smoothly and has a long service life;

10. Four unilateral couplers, equipped with couplings and pins;

11. Color: Medium yellow, surrounded by orange warning stripes.

5 ton guardrail type flat trailer, full trailer Nangong has been producing in large quantities for many years. It is a factory integrating R&D, production and sales, with low cost, good quality and excellent price.

Application: Small flatbed trailers are commonly used for short distance turnover transportation in light industries such as hardware, electrical appliances, furniture, printing, etc.
