Brand: Nangong, Model: NGTT15S-22/60-8S, Load capacity: 15 tons, Board size: 6 * 2.2 meters, Net weight: 3256KG;

15 ton concave flatbed trailer detailed parameters:

1. The load-bearing capacity of this flatbed truck is 15T, the main beam of the platform is made of 20 # steel, the auxiliary beam is made of 12 # steel, and the board surface is paved with 4mm patterned plates;

The platform width is 2.2 meters and the total length is 6 meters. The size of the middle recess and the height above the ground shall be executed according to the specific plan confirmed by both parties.

2. This car has 8 models of 18 * 9-12 press fit solid tires, with a single wheel load capacity of 3T and a rated speed of 15KM/H.

3. This car is equipped with spring shock absorbers.

4. The left and right rotation angle of the front wheels is 180 degrees, which facilitates small radius turning.

5. The steering mechanism is a (15T) rotary table machine rotary assembly.

6. Install a connector and a pin when shipping.

7. Color: Fire red, with black stripes sprayed around.

The tool trailer for the 15 ton concave flatbed trailer electromechanical group equipment is customized for Nangong non-standard. The Nangong trailer is designed according to customer requirements, with heavy load capacity, good quality, fast delivery, and long service life.

Application scenarios: The flatbed truck is generally used for transportation in airports, ports, train stations, factories, and large warehouses. This vehicle is used for the transportation of mechanical and electrical equipment.
